MODEL NO. :
EGL J800
(JEWELLERY PCB)
WEIGHING SCALE
Jewellery-grade precision. The J800 runs the 24-bit ADS1130 (Texas Instruments USA) with a 5-key keyboard and front on/off — tuned for jewellery workflows that need 5–10 mg resolution from 5 g up to 600 g. Pairs with the LAK-B miniature load cell and Eagle Weigh's jewellery-specific firmware.
Specifications
| MODEL | J800 |
| ADC | ADS1130 Texas Instruments U.S.A. |
| SOFTWARE | 7777 Bobby |
| PCB SIZE | 76 × 86.40 mm |
| PCB GRADE | 1.6 mm thickness · FR4 |
| HOLE MOUNTING SIZE | 70 × 80 mm |
| KEYPAD | 5-key with front on/off |
| MODE FUNCTIONS | Hold / piece-counting / kg / litre |
| DISPLAY COMPATIBLE | 0.56″, 0.8″, 1″ inches |
| 7 SEGMENT DISPLAY | 6 + 8 wire set |
| RS-232 INTERFACE | YES |
Specifications
| CAPACITY | 3 cap. with 3 step accuracy |
| DUMMY ZERO | YES |
| AIR LOCKING | YES |
| AUTO ZERO | YES |
| CAL LOCK | YES |
| BUZZER PORT | YES |
| SLEEP MODE | YES |
| BATTERY VOLT IND. | NO |
| BATTERY BACKUP | Up to 50 hours |
| BATTERY SUPPORT | 6 VOLTS |
| THREE WIRE DISPLAY | YES |
| ACCURACY | 5 / 10 mg → 600 g |
Features
Built into every Eagle Weigh card.
- ✓24-bit ADS1130 ADC (Texas Instruments USA) for jewellery resolution
- ✓5-key keypad with front on/off — designed for jewellery shops
- ✓6 + 8-wire 7-segment display set
- ✓Three-wire display support for remote/customer-facing units
- ✓5/10 mg resolution from 5 g up to 600 g
- ✓Pairs with LAK-B miniature load cell
Used in
Where this card ships.
Jewellery shopsAssayersGold testing labsPrecision micro-weighing
Compare with
Other cards in the family.
QUALITY PRODUCT
1 YEAR WARRANTY
TESTED & CALIBRATED
MOISTURE PROOF
Specify · Quote · Ship
Need the EGL J800 for your build?
Tell us the application, the capacity and the volume — we come back with a price-and-lead-time within one business day.
ModelEGL J800
CategoryWeighing Scale PCB
OriginMade in India · Samaypur, Delhi
Warranty1 year from invoice
